Cylindrical Roller Bearings

Bearing Overview

Cylindrical roller bearings are designed to carry heavy radial loads and operate at high speeds. Featuring cylindrical rollers in linear contact with the raceways, they offer high rigidity and load-carrying capacity. These roller bearings are available in various designs such as NU, NJ, NUP, and N types, allowing for axial displacement or fixed positioning. They are widely used in gearboxes, electric motors, machine tools, and steel machinery. Our cylindrical roller bearings deliver low friction, stable performance, and long service life under demanding conditions.

Bearing Series

– Single Row:
N type, NU type, NJ type, NUP type, NF type, NH type

– Double Row:
NN type, NNU type

…Many other bearing models and series are not listed here. If you have any specific requirements or questions, feel free to contact us.

Model NO.			Dimensions（mm）
N	NU	NJ	d	D	B
N 1005	NU 1005	NJ 1005	25	47	12
N 1006	NU 1006	NJ 1006	30	55	13
N 1007	NU 1007	NJ 1007	35	62	14
N 1008	NU 1008	NJ 1008	40	68	15
N 1009	NU 1009	NJ 1009	45	75	16
N 1010	NU 1010	NJ 1010	50	80	16
N 1011	NU 1011	NJ 1011	55	90	18
N 1012	NU 1012	NJ 1012	60	95	18
N 1013	NU 1013	NJ 1013	65	100	18
N 1014	NU 1014	NJ 1014	70	110	20
N 1015	NU 1015	NJ 1015	75	115	20
N 1016	NU 1016	NJ 1016	80	125	22
N 1017	NU 1017	NJ 1017	85	130	22
N 1018	NU 1018	NJ 1018	90	140	24
N 1019	NU 1019	NJ 1019	95	145	24
N 1020	NU 1020	NJ 1020	100	150	24
N 1021	NU 1021	NJ 1021	105	160	26
N 1022	NU 1022	NJ 1022	110	170	28
N 1024	NU 1024	NJ 1024	120	180	28
N 1026	NU 1026	NJ 1026	130	200	33
N 1028	NU 1028	NJ 1028	140	210	33
N 1030	NU 1030	NJ 1030	150	225	35
N 1032	NU 1032	NJ 1032	160	240	38
N 1034	NU 1034	NJ 1034	170	260	42
N 1036	NU 1036	NJ 1036	180	280	46
N 1038	NU 1038	NJ 1038	190	290	46
N 1040	NU 1040	NJ 1040	200	310	51
N 1044	NU 1044	NJ 1044	220	340	56
N 1048	NU 1048	NJ 1048	240	360	56
N 1052	NU 1052	NJ 1052	260	400	65
N 1056	NU 1056	NJ 1056	280	420	65
N 1060	NU 1060	NJ 1060	300	460	74
N 1064	NU 1064	NJ 1064	320	480	74
N 1068	NU 1068	NJ 1068	340	520	82
N 1072	NU 1072	NJ 1072	360	540	82
N 1076	NU 1076	NJ 1076	380	560	82
N 1080	NU 1080	NJ 1080	400	600	90
N 1084	NU 1084	NJ 1084	420	620	90
N 1088	NU 1088	NJ 1088	440	650	94
N 1092	NU 1092	NJ 1092	460	680	100
N 1096	NU 1096	NJ 1096	480	700	100
N 202	NU 202	NJ 202	15	35	11
N 203	NU 203	NJ 203	17	40	12
N 204	NU 204	NJ 204	20	47	14
N 205	NU 205	NJ 205	25	52	15
N 206	NU 206	NJ 206	30	62	16
N 207	NU 207	NJ 207	35	72	17
N 208	NU 208	NJ 208	40	80	18
N 209	NU 209	NJ 209	45	85	19
N 210	NU 210	NJ 210	50	90	20
N 211	NU 211	NJ 211	55	100	21
N 212	NU 212	NJ 212	60	110	22
N 213	NU 213	NJ 213	65	120	23
N 214	NU 214	NJ 214	70	125	24
N 215	NU 215	NJ 215	75	130	25
N 216	NU 216	NJ 216	80	140	26
N 217	NU 217	NJ 217	85	150	28
N 218	NU 218	NJ 218	90	160	30
N 219	NU 219	NJ 219	95	170	32
N 220	NU 220	NJ 220	100	180	34
N 221	NU 221	NJ 221	105	190	36
N 222	NU 222	NJ 222	110	200	38
N 224	NU 224	NJ 224	120	215	40
N 226	NU 226	NJ 226	130	230	40
N 228	NU 228	NJ 228	140	250	42
N 230	NU 230	NJ 230	150	270	45
N 232	NU 232	NJ 232	160	290	48
N 234	NU 234	NJ 234	170	310	52
N 236	NU 236	NJ 236	180	320	52
N 238	NU 238	NJ 238	190	340	55
N 240	NU 240	NJ 240	200	360	58
N 244	NU 244	NJ 244	220	400	65
N 248	NU 248	NJ 248	240	440	72
N 252	NU 252	NJ 252	260	480	80
N 256	NU 256	NJ 256	280	500	80
N 260	NU 260	NJ 260	300	540	85
N 264	NU 264	NJ 264	320	580	92
N 2203	NU 2203	NJ 2203	17	40	16
N 2204	NU 2204	NJ 2204	20	47	18
N 2205	NU 2205	NJ 2205	25	52	18
N 2206	NU 2206	NJ 2206	30	62	20
N 2207	NU 2207	NJ 2207	35	72	23
N 2208	NU 2208	NJ 2208	40	80	23
N 2209	NU 2209	NJ 2209	45	85	23
N 2210	NU 2210	NJ 2210	50	90	23
N 2211	NU 2211	NJ 2211	55	100	25
N 2212	NU 2212	NJ 2212	60	110	28
N 2213	NU 2213	NJ 2213	65	120	31
N 2214	NU 2214	NJ 2214	70	125	31
N 2215	NU 2215	NJ 2215	75	130	31
N 2216	NU 2216	NJ 2216	80	140	33
N 2217	NU 2217	NJ 2217	85	150	36
N 2218	NU 2218	NJ 2218	90	160	40
N 2219	NU 2219	NJ 2219	95	170	43
N 2220	NU 2220	NJ 2220	100	180	46
N 2222	NU 2222	NJ 2222	110	200	53
N 2224	NU 2224	NJ 2224	120	215	58
N 2226	NU 2226	NJ 2226	130	230	64
N 2228	NU 2228	NJ 2228	140	250	68
N 2230	NU 2230	NJ 2230	150	270	73
N 2232	NU 2232	NJ 2232	160	290	80
N 2234	NU 2234	NJ 2234	170	310	86
N 2236	NU 2236	NJ 2236	180	320	86
N 2238	NU 2238	NJ 2238	190	340	92
N 2240	NU 2240	NJ 2240	200	360	98
N 303	NU 303	NJ 303	17	47	14
N 304	NU 304	NJ 304	20	52	15
N 305	NU 305	NJ 305	25	62	17
N 306	NU 306	NJ 306	30	72	19
N 307	NU 307	NJ 307	35	80	21
N 308	NU 308	NJ 308	40	90	23
N 309	NU 309	NJ 309	45	100	25
N 310	NU 310	NJ 310	50	110	27
N 311	NU 311	NJ 311	55	120	29
N 312	NU 312	NJ 312	60	130	31
N 313	NU 313	NJ 313	65	140	33
N 314	NU 314	NJ 314	70	150	35
N 315	NU 315	NJ 315	75	160	37
N 316	NU 316	NJ 316	80	170	39
N 317	NU 317	NJ 317	85	180	41
N 318	NU 318	NJ 318	90	190	43
N 319	NU 319	NJ 319	95	200	45
N 320	NU 320	NJ 320	100	215	47
N 321	NU 321	NJ 321	105	225	49
N 322	NU 322	NJ 322	110	240	50
N 324	NU 324	NJ 324	120	260	55
N 326	NU 326	NJ 326	130	280	58
N 328	NU 328	NJ 328	140	300	62
N 330	NU 330	NJ 330	150	320	65
N 332	NU 332	NJ 332	160	340	68
N 334	NU 334	NJ 334	170	360	72
N 336	NU 336	NJ 336	180	380	75
N 338	NU 338	NJ 338	190	400	78
N 340	NU 340	NJ 340	200	420	80
N 344	NU 344	NJ 344	220	460	88
N 348	NU 348	NJ 348	240	500	95
N 352	NU 352	NJ 352	260	540	102
N 2304	NU 2304	NJ 2304	20	52	21
N 2305	NU 2305	NJ 2305	25	62	24
N 2306	NU 2306	NJ 2306	30	72	27
N 2307	NU 2307	NJ 2307	35	80	31
N 2308	NU 2308	NJ 2308	40	90	33
N 2309	NU 2309	NJ 2309	45	100	36
N 2310	NU 2310	NJ 2310	50	110	40
N 2311	NU 2311	NJ 2311	55	120	43
N 2312	NU 2312	NJ 2312	60	130	46
N 2313	NU 2313	NJ 2313	65	140	48
N 2314	NU 2314	NJ 2314	70	150	51
N 2315	NU 2315	NJ 2315	75	160	55
N 2316	NU 2316	NJ 2316	80	170	58
N 2317	NU 2317	NJ 2317	85	180	60
N 2318	NU 2318	NJ 2318	90	190	64
N 2319	NU 2319	NJ 2319	95	200	67
N 2320	NU 2320	NJ 2320	100	215	73
N 2322	NU 2322	NJ 2322	110	240	80
N 2324	NU 2324	NJ 2324	120	260	86
N 2326	NU 2326	NJ 2326	130	280	93
N 2328	NU 2328	NJ 2328	140	300	102
N 2330	NU 2330	NJ 2330	150	320	108
N 2332	NU 2332	NJ 2332	160	340	114
N 406	NU 406	NJ 406	30	90	23
N 407	NU 407	NJ 407	35	100	25
N 408	NU 408	NJ 408	40	110	27
N 409	NU 409	NJ 409	45	120	29
N 410	NU 410	NJ 410	50	130	31
N 411	NU 411	NJ 411	55	140	33
N 412	NU 412	NJ 412	60	150	35
N 413	NU 413	NJ 413	65	160	37
N 414	NU 414	NJ 414	70	180	42
N 415	NU 415	NJ 415	75	190	45
N 416	NU 416	NJ 416	80	200	48
N 417	NU 417	NJ 417	85	210	52
N 418	NU 418	NJ 418	90	225	54
N 419	NU 419	NJ 419	95	240	55
N 420	NU 420	NJ 420	100	250	58
N 421	NU 421	NJ 421	105	260	60
N 422	NU 422	NJ 422	110	280	65
N 424	NU 424	NJ 424	120	310	72
N 426	NU 426	NJ 426	130	340	78
N 428	NU 428	NJ 428	140	360	82
N 430	NU 430	NJ 430	150	380	85

Model NO.	Dimensions（mm）
Model NO.	d	D	B
NN 4920	100	140	40
NN 4921	105	145	40
NN 4922	110	150	40
NN 4924	120	165	45
NN 4926	130	180	50
NN 4928	140	190	50
NN 4930	150	210	60
NN 4932	160	220	60
NN 4934	170	230	60
NN 4936	180	250	69
NN 4938	190	260	69
NN 4940	200	280	80
NN 4944	220	300	80
NN 4948	240	320	80
NN 4952	260	360	100
NN 4956	280	380	100
NN 4960	300	420	118
NN 4964	320	440	118
NN 3005	25	47	16
NN 3006	30	55	19
NN 3007	35	62	20
NN 3008	40	68	21
NN 3009	45	75	23
NN 3010	50	80	23
NN 3011	55	90	26
NN 3012	60	95	26
NN 3013	65	100	26
NN 3014	70	110	30
NN 3015	75	115	30
NN 3016	80	125	34
NN 3017	85	130	34
NN 3018	90	140	37
NN 3019	95	145	37
NN 3020	100	150	37
NN 3021	105	160	41
NN 3022	110	170	45
NN 3024	120	180	46
NN 3026	130	200	52
NN 3028	140	210	53
NN 3030	150	225	56
NN 3032	160	240	60
NN 3034	170	260	67
NN 3036	180	280	74
NN 3038	190	290	75
NN 3040	200	310	82
NN 3044	220	340	90
NN 3048	240	360	92
NN 3052	260	400	104
NN 3056	280	420	106
NN 3060	300	460	118
NN 3064	320	480	121
NN 3068	340	520	133
NN 3072	360	540	134
NN 3076	380	560	135
NN 3080	400	600	148
NN 3084	420	620	150
NN 3088	440	650	157
NN 3092	460	680	163
NN 3096	480	700	165
NN 30/500	500	720	167
NN 30/530	530	780	185
NN 30/560	560	820	195
NN 30/600	600	870	200
NN 30/630	630	920	212
NN 30/670	670	980	230
NNU 4920	100	140	40
NNU 4921	105	145	40
NNU 4922	110	150	40
NNU 4924	120	165	45
NNU 4926	130	180	50
NNU 4928	140	190	50
NNU 4930	150	210	60
NNU 4932	160	220	60
NNU 4934	170	230	60
NNU 4936	180	250	69
NNU 4938	190	260	69
NNU 4940	200	280	80
NNU 4944	220	300	80
NNU 4948	240	320	80
NNU 4952	260	360	100
NNU 4956	280	380	100
NNU 4960	300	420	118
NNU 4964	320	440	118
NNU 4968	340	460	118
NNU 4972	360	480	118
NNU 4976	380	520	140
NNU 4980	400	540	140
NNU 4984	420	560	140
NNU 4988	440	600	160
NNU 4992	460	620	160
NNU 4996	480	650	170
NNU 49/500	500	670	170
NNU 49/530	530	710	180
NNU 49/560	560	750	190
NNU 49/600	600	800	200
NNU 49/630	630	850	218
NNU 49/670	670	900	230
NNU 49/710	710	950	243
NNU 49/750	750	1000	250
NNU 4120	100	165	65
NNU 4121	105	175	69
NNU 4122	110	180	69
NNU 4124	120	200	80
NNU 4126	130	210	80
NNU 4128	140	225	85
NNU 4130	150	250	100
NNU 4132	160	270	109
NNU 4134	170	280	109
NNU 4136	180	300	118
NNU 4138	190	320	128
NNU 4140	200	340	140
NNU 4144	220	370	150
NNU 4148	240	400	160
NNU 4152	260	440	180
NNU 4156	280	460	180
NNU 4160	300	500	200
NNU 4164	320	540	218
NNU 4168	340	580	243
NNU 4172	360	600	243
NNU 4176	380	620	243
NNU 4180	400	650	250
NNU 4184	420	700	280
NNU 4188	440	720	280
NNU 4192	460	760	300
NNU 4196	480	790	308
NNU 41/500	500	830	325
NNU 41/530	530	870	335
NNU 41/560	560	920	355
NNU 41/600	600	980	375
NNU 41/630	630	1030	400
NNU 41/670	670	1090	412
NNU 41/710	710	1150	438
NNU 41/750	750	1220	475
NNU 41/800	800	1280	475

Q & A

Are you a trading company or a manufacturer?

We are not only a professional bearing manufacturer, but also a highly experienced trading company.
This enables us to supply a wide range of bearing products — both those we produce ourselves and those sourced from reliable partners — to meet diverse customer needs.

Can I visit your factory?

Sure, you’re welcome to visit our factory anytime!
Just let us know your schedule in advance, and we’ll arrange everything for you.

Can we take some samples? Any fees?

Yes, we can provide free samples, but the shipping cost is on your side.
If you place an order after confirming the sample, we will refund the shipping fee or deduct it from the order total.

What are the loading ports?

Our primary loading port is Qingdao, but we can also ship from Shanghai, Tianjin or other ports in China as needed.

Is there quality inspection before loading?

Of course. All our products undergo strict quality inspection before packing. Any that do not meet the standards are rejected and discarded.
Customers are also welcome to arrange third-party inspections before loading.
